Fig. 2
- ID
- ZDB-FIG-110317-12
- Publication
- Osborn et al., 2011 - Cdkn1c drives muscle differentiation through a positive feedback loop with Myod
- Other Figures
- (all 11)
- All Figure Page
- Back to All Figure Page
Myod-driven myogenin expression permits slow fibre formation in shha mutant. Myog mRNA or MyHC accumulation in uninjected, myod MO- or myog MO-injected embryos from wild type or shhatbx/+ in-cross. Dorsal flatmounts of 5 ss (A,B) or 10–15 ss (C) embryos. Bar: 100 Μm. (A). Myog mRNA is ablated by myod MO injection into wild type. (B) Myod and myog MOs each delay adaxial myogenesis. (C) Myod and myog, but not myf5, MOs ablate adaxial myogenesis in shhatbx392 mutants (21/79), but not from siblings. |
Genes: | |
---|---|
Antibodies: | |
Fish: | (all 8) |
Knockdown Reagents: | |
Anatomical Terms: | |
Stage Range: | 5-9 somites to 10-13 somites |
Fish: |
|
---|---|
Knockdown Reagents: | |
Observed In: | |
Stage Range: | 5-9 somites to 10-13 somites |
Reprinted from Developmental Biology, 350(2), Osborn, D.P., Li, K., Hinits, Y., and Hughes, S.M., Cdkn1c drives muscle differentiation through a positive feedback loop with Myod, 464-475, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
