Fig. 4
- ID
- ZDB-FIG-141230-23
- Publication
- Amacher et al., 2002 - The zebrafish T-box genes no tail and spadetail are required for development of trunk and tail mesoderm and medial floor plate
- Other Figures
- (all 9)
- All Figure Page
- Back to All Figure Page
Neither spt nor ntl function is required for most dorsal-ventral spinal cord patterning. (A,E,I,M) Wild-type, (B,F,J,N) ntl–, (C,G,K,O) spt–, and (D,H,L,P) spt–;ntl– embryos. (A-D) pax2.1 interneuron expression at 24 hpf, (E-L) islet1 expression at the 8-10 somite stage (13-14 hpf); arrowheads indicate primary motoneurons and arrows indicate Rohon-Beard neurons. (M-P) sonic hedgehog (shh) and krox20 expression at the late gastrula stage (<9.5 hpf). Transverse sections (A-D; I-L) are approximately from midtrunk levels. Anterior is to the top. Scale bars: 25 μm (A-D and I-L), 100 μm (E-H and M-P). |
Genes: | |
---|---|
Fish: | |
Anatomical Terms: | (all 6) |
Stage Range: | 90%-epiboly to Prim-5 |
Fish: | |
---|---|
Observed In: | |
Stage Range: | 5-9 somites to Prim-5 |
