Fig. 2
- ID
- ZDB-FIG-141230-21
- Publication
- Amacher et al., 2002 - The zebrafish T-box genes no tail and spadetail are required for development of trunk and tail mesoderm and medial floor plate
- Other Figures
- (all 9)
- All Figure Page
- Back to All Figure Page
spt and ntl are required together for trunk and tail mesoderm development. (A-D) Live wild-type and mutant embryos at 24 hpf. Embryos doubly homozygous for spt and ntl mutations (D) have more severe posterior mesodermal deficiencies than ntl– (B) and spt– (C) embryos. Anterior development appears unperturbed. (E-H) Tranverse sections through trunk regions of wild-type (E) and mutant embryos (F-H) at 30 hpf show that (F) ntl– embryos lack a differentiated notochord, (G) spt– embryos have reduced muscle tissue, and (H) spt–;ntl– embryos lack all recognizable mesoderm, having only a spinal cord covered by skin. sc, spinal cord; no, notochord; sm, somitic muscle; *, pronephric tubule. Scale bars, 250 μm (A), 25 μm (E). |
Fish: | |
---|---|
Observed In: | (all 9) |
Stage Range: | Prim-5 to Prim-15 |
