Fig. 7

Transfating of pronephric cells in the mind bomb mutant. (A,B) shippo1 expression in control wild-type embryos is restricted to single cells (A), whereas, in mind bomb homozygotes (B), pronephric distal segment cells (ds) are uniformly positive and there is an increase in shippo1-positive cells in the proximal segment (ps). (C,D) Wild-type jagged 2 expression (C) is also expanded in mind bomb homozygotes (D). (E,G) trpM7 (E) and slc13a1 (G) expression is almost completely lost in mind bomb homozygotes (F and H, respectively).

Expression Data

Genes:	cimap1b jag2b slc13a1 trpm7
Fish:	WT mib1^m132/m132 (AB)
Anatomical Term:	pronephros
Stage:	Prim-15

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	mib1^m132/m132 (AB)
Observed In:	cell differentiation involved in pronephros development pronephros
Stage:	Prim-15

Phenotype Detail
