Fig. S6

Labeled cells are restricted to the myeloid lineage. (A and B) EGFP expression within 48 hpf lysC::EGFP transgenic larvae. (C and D) EGFP expression within 48 hpf lysC::EGFP transgenic larvae following early delivery of scl-targeting MOs. Arrows in D denote pericardial edema. (E and F) EGFP expression within 28 hpf lysC::EGFP embryo and 28 hpf transgenic embryo following early delivery of gata1-targeting MOs, respectively. (A/C/E/F and B/D) Lateral views of tail/trunk and dorsal views of cranio-trunk region, respectively, anterior to left. Scale bars: 200 μm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-gata1a WT + MO4-tal1
Knockdown Reagents:	MO1-gata1a MO4-tal1
Observed In:	heart myeloid cell
Stage Range:	Prim-5 to Long-pec

Phenotype Detail
