Fig. 8

Formation and migration of posterior lateral line primordium (PLLp), and deposition of proneuromasts (Pnm) and neuromasts (nm) in control embryos and embryos injected with RcadMphA as shown by whole mount in situ hybridization using cadherin2 (cdh2, A-F) or cxcr4b (G-J) cRNA probes. C: Lateral view of the mid trunk and tail region of a control embryo, while the remaining panels show lateral views of the mid trunk region of control embryos and cdh4 morphants, with anterior to the left and dorsal up.

Expression Data

Genes:	cdh2 cxcr4b
Fish:	WT WT + MO1-cdh4
Knockdown Reagent:	MO1-cdh4
Anatomical Terms:	neuromast posterior lateral line primordium
Stage Range:	Prim-5 to High-pec

Expression Detail

Gene	Fish	Conditions	Stage	Anatomy	Assay
cdh2	WT	control	Prim-5	neuromast	ISH
cdh2	WT	control	Prim-5	posterior lateral line primordium	ISH
cdh2	WT	control	Prim-15	neuromast	ISH
cdh2	WT	control	Prim-15	posterior lateral line primordium	ISH
cdh2	WT	control	High-pec	neuromast	ISH
cdh2	WT	control	High-pec	posterior lateral line primordium	ISH
cdh2	WT + MO1-cdh4	standard conditions	Prim-5	neuromast	ISH
cdh2	WT + MO1-cdh4	standard conditions	Prim-5	posterior lateral line primordium	ISH
cdh2	WT + MO1-cdh4	standard conditions	Prim-15	neuromast	ISH
cdh2	WT + MO1-cdh4	standard conditions	Prim-15	posterior lateral line primordium	ISH

1 - 10 of 16

Show

Antibody Labeling

No data available

Phenotype Data

Fish:	WT + MO1-cdh4
Knockdown Reagent:	MO1-cdh4
Observed In:	posterior lateral line neuromast primordium migration
Stage:	High-pec

Phenotype Detail

Fish	Conditions	Stage	Phenotype
WT + MO1-cdh4	standard conditions	High-pec	posterior lateral line neuromast primordium migration decreased rate, abnormal

1 - 1 of 1

Show
