Fig. 6

Dorsal markers are reduced in dullahan mutants. chordin mRNA expression in wild-type (A, A’) and dul (B, B’) embryos at 6.0 and 8.0 hpf, respectively. A and A’ are animal views, dorsal to the right. B and B’ are dorsal views. The number of embryos with the shown expression pattern of the total embryos examined is indicated in the upper right or left (inset) corner. goosecoid mRNA expression in wild-type (C, C’) and dul (D, D’) embryos at 6.0 and 8.0 hpf, respectively. The numbers in the lower right corner indicate the number of embryos with any positive goosecoid signal of the total embryos examined.

Expression Data

Genes:	chrd gsc
Fish:	WT dun^{p15uzat/p15uzat}
Anatomical Terms:	gastrula cell shield
Stage:	Shield

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	dun^{p15uzat/p15uzat}
Observed In:	gastrula cell shield
Stage:	Shield

Phenotype Detail
