Fig. 3

Morphology, histopathological examination and vascular structure in ethanol-treated and untreated larvae. (A-C) Morphological characteristics of ethanol-treated and untreated larvae at 6dpf. (D-I) H&E staining of transverse sections at site of abdomen in untreated and ethanol-treated larvae. Boxed areas in D,F,H magnified in E,G,I. (J,L,N) Reconstructed images of vascular structure in untreated and ethanol-treated larvae by confocal imaging. (K,M,O) Tomography of vascular structure in control and alcohol-treated larvae by confocal imaging. Asterisk in N,O indicates destruction in dorsal aorta.

Expression Data

Gene:	EGFP
Fish:	y1Tg
Condition:	chemical treatment by environment: ethanol
Anatomical Terms:	dorsal aorta trunk vasculature blood vessel
Stage:	Day 6

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	AB y1Tg
Condition:	chemical treatment by environment: ethanol
Observed In:	dorsal aorta intersegmental artery muscle pericardium trunk vasculature blood vessel
Stage:	Day 6

Phenotype Detail
