Fig. 5

Sensory hair cells within neuromasts of both cobl- and syndapin I-morphant zebrafish larvae are not functional. (A,D,G,J) Confocal images of representative posterior lateral line neuromasts of wild-type, p53-, sdpI- and cobl-morphant transgenic claudinB:lyn(GFP) larvae at 4dpf. Hair cells are organized symmetrically in rosettes in wild-type (A), control-injected (D), syndapin I (G) and cobl morphants (J). (B,E,H,K) FM 4-64FX vital dye labeling shows a lack of dye uptake in syndapin I (H) and cobl (K) morphants in comparison with wild-type (B) and control-injected larvae (E). (C,F,I,L) Merged images of the mostly apical FM-labeling of vesicular structures and claudin-GFP. Scale bar: 20 μm.

Expression Data

Gene:	EGFP
Fish:	zf106Tg zf106Tg + MO2-pacsin1b zf106Tg + MO3-cobl zf106Tg + MO4-tp53
Knockdown Reagents:	MO2-pacsin1b MO3-cobl MO4-tp53
Anatomical Term:	neuromast
Stage:	Day 4

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
