FIGURE

Fig. S5

ID

ZDB-FIG-080828-80

Publication

Yanicostas et al., 2008 - Essential requirement for zebrafish anosmin-1a in the migration of the posterior lateral line primordium

Other Figures

(all 13)

All Figure Page

Back to All Figure Page

Fig. S5

Kal1a inactivation compromises terminal elongation of the PLLP nerve within the migrating primordium. Acetylated β-tubulin immunostaining of the PLLP nerve (A′, B′, C′ and D′) in ClaudinB::GFP embryos (A, B) and following injection of MO kal1a (0.5 mM) (C, D). Magnified views of the primordium shown in A (B), A′ (B′), A″ (B″), C (D), C′ (D′) and C″ (D″). Merge images of the photographs shown in A and A′ (A″), B and B′ (B″), C and C′ (C″) and D and D′ (D″). Arrows indicate the distal edge of the PLLP nerve. v: vitellus, e: ear.

Expression Data

Gene:	EGFP
Fish:	zf106Tg zf106Tg + MO2-anos1a
Knockdown Reagent:	MO2-anos1a
Anatomical Terms:	inner ear posterior lateral line primordium
Stage:	Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	zf106Tg + MO2-anos1a
Knockdown Reagent:	MO2-anos1a
Observed In:	neuromast primordium migration posterior lateral line nerve posterior lateral line nerve development
Stage:	Prim-5

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 320(2), Yanicostas, C., Ernest, S., Dayraud, C., Petit, C., and Soussi-Yanicostas, N., Essential requirement for zebrafish anosmin-1a in the migration of the posterior lateral line primordium, 469-479, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
