Fig. 4

ID: ZDB-IMAGE-081010-9
Publication: Gansner et al., 2008 - Essential role for fibrillin-2 in zebrafish notochord and vascular morphogenesis
All Figures: Figures for Gansner et al., 2008


Figure Caption

Fig. 4 pfd^gw1 mutants are sensitized to pharmacologic inhibition of lysyl oxidase. A-F: Clutches from pfd^gw1/+ intercrosses were incubated in vehicle (A,B), the copper chelator neocuproine (2 μM; C,D), or the lysyl oxidase inhibitor β-aminopropionitrile (1 mM; E,F). Notochord is normal in wild-type embryos treated with vehicle or neocuproine (A,C) and shows a very mild herniation event in β-aminopropionitrile (E, arrowhead). Notochords of pfd^gw1 mutants in neocuproine and β-aminopropionitrile (D,F, arrowheads) are substantially more distorted than mutants incubated in vehicle (B, arrowhead). Embryos were incubated in PTU to inhibit melanin pigmentation and photographed at 30 hours postfertilization (hpf).

Figure Data

Phenotype details
